FDBL0090N40 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-HPSOF
- Description: MOSFET N-CH 40V 240A 8HPSOF
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDBL0090N40 Specifications:
- MfrPart.: FDBL0090N40
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: MOSFET N-CH 40V 240A 8HPSOF
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: PowerTrench®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 240A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 0.9mOhm @ 80A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 188 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 12 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 357W (Tj)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-HPSOF
- FDBL0090N40 onsemi (ON), MOSFET N-CH 40V 240A 8HPSOF, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDBL0090N40, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
