FDB3502 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D²PAK
- Description: MOSFET N-CH 75V 6A/14A TO263AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDB3502 Specifications:
- MfrPart.: FDB3502
- Mfr: onsemi
- Description: MOSFET N-CH 75V 6A/14A TO263AB
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerTrench®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 75 V
- Current-ContinuousDrain(Id)@25°C: 6A (Ta), 14A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 47mOhm @ 6A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 15 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 815 pF @ 40 V
- FETFeature: -
- PowerDissipation(Max): 3.1W (Ta), 41W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D²PAK
- FDB3502 onsemi (ON), MOSFET N-CH 75V 6A/14A TO263AB, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDB3502, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
