FDB120N10 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D²PAK
- Description: MOSFET N-CH 100V 74A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDB120N10 Specifications:
- MfrPart.: FDB120N10
- Mfr: onsemi
- Description: MOSFET N-CH 100V 74A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerTrench®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 74A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 12mOhm @ 74A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 86 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 5605 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 170W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D²PAK
- FDB120N10 onsemi (ON), MOSFET N-CH 100V 74A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDB120N10, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
