FDB024N08BL7 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-263-7
- Description: MOSFET N-CH 80V 120A TO263-7
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDB024N08BL7 Specifications:
- MfrPart.: FDB024N08BL7
- Mfr: onsemi
- Description: MOSFET N-CH 80V 120A TO263-7
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerTrench®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 80 V
- Current-ContinuousDrain(Id)@25°C: 120A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 2.4mOhm @ 100A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 178 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 13530 pF @ 40 V
- FETFeature: -
- PowerDissipation(Max): 246W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-263-7
- FDB024N08BL7 onsemi (ON), MOSFET N-CH 80V 120A TO263-7, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
