FCPF1300N80ZYD Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220F-3 (Y-Forming)
- Description: MOSFET N-CH 800V 4A TO220F-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FCPF1300N80ZYD Specifications:
- MfrPart.: FCPF1300N80ZYD
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: MOSFET N-CH 800V 4A TO220F-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: SuperFET® II
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 4A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 1.3Ohm @ 2A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 400µA
- GateCharge(Qg)(Max)@Vgs: 21 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 880 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 24W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220F-3 (Y-Forming)
- FCPF1300N80ZYD onsemi (ON), MOSFET N-CH 800V 4A TO220F-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
