FCP220N80 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220-3
- Description: MOSFET N-CH 800V 23A TO220-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FCP220N80 Specifications:
- MfrPart.: FCP220N80
- Mfr: onsemi
- Description: MOSFET N-CH 800V 23A TO220-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: SuperFET® II
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 23A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 220mOhm @ 11.5A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 2.3mA
- GateCharge(Qg)(Max)@Vgs: 105 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 4560 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 278W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220-3
- FCP220N80 onsemi (ON), MOSFET N-CH 800V 23A TO220-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FCP220N80, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
