FCHD125N65S3R0-F155 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247
- Description: MOSFET N-CH 650V 24A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FCHD125N65S3R0-F155 Specifications:
- MfrPart.: FCHD125N65S3R0-F155
- Mfr: onsemi
- Description: MOSFET N-CH 650V 24A TO247
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: SuperFET® III
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 650 V
- Current-ContinuousDrain(Id)@25°C: 24A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 125mOhm @ 12A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 590µA
- GateCharge(Qg)(Max)@Vgs: 46 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 1940 pF @ 400 V
- FETFeature: -
- PowerDissipation(Max): 181W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247
- FCHD125N65S3R0-F155 onsemi (ON), MOSFET N-CH 650V 24A TO247, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
