FCD850N80Z Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252AA
- Description: MOSFET N-CH 800V 6A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FCD850N80Z Specifications:
- MfrPart.: FCD850N80Z
- Mfr: onsemi
- Description: MOSFET N-CH 800V 6A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: SuperFET® II
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 6A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 850mOhm @ 3A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 600µA
- GateCharge(Qg)(Max)@Vgs: 29 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1315 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 75W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252AA
- FCD850N80Z onsemi (ON), MOSFET N-CH 800V 6A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
