FCA22N60N Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-3PN
- Description: MOSFET N-CH 600V 22A TO3PN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FCA22N60N Specifications:
- MfrPart.: FCA22N60N
- Mfr: onsemi
- Description: MOSFET N-CH 600V 22A TO3PN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: SupreMOS™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 22A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 165mOhm @ 11A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 45 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 1950 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 205W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-3PN
- FCA22N60N onsemi (ON), MOSFET N-CH 600V 22A TO3PN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
