ECH8649-TL-H onsemi POWER, N-CHANNEL, MOSFET
ECH8649-TL-H Images
ECH8649-TL-H Images
ECH8649-TL-H
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-SMD, Flat Lead
  • Description: POWER, N-CHANNEL, MOSFET
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ECH8649-TL-H Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
ECH8649-TL-H Specifications:
  • MfrPart.: ECH8649-TL-H
  • Mfr: onsemi
  • Description: POWER, N-CHANNEL, MOSFET
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • FETType: 2 N-Channel (Dual)
  • FETFeature: Logic Level Gate
  • DraintoSourceVoltage(Vdss): 20V
  • Current-ContinuousDrain(Id)@25°C: 7.5A
  • RdsOn(Max)@IdVgs: 17mOhm @ 4A, 4.5V
  • Vgs(th)(Max)@Id: -
  • GateCharge(Qg)(Max)@Vgs: 10.8nC @ 4.5V
  • InputCapacitance(Ciss)(Max)@Vds: 1060pF @ 10V
  • Power-Max: 1.5W
  • OperatingTemperature: 150°C (TJ)
  • MountingType: Surface Mount
  • Package/Case: 8-SMD, Flat Lead
  • ECH8649-TL-H onsemi (ON), POWER, N-CHANNEL, MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
