ECH8502-TL-H Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays Package/Case: 8-SMD, Flat Lead
- Description: TRANS NPN/PNP 100V/50V 5A 8ECH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ECH8502-TL-H Specifications:
- MfrPart.: ECH8502-TL-H
- Mfr: onsemi
- Description: TRANS NPN/PNP 100V/50V 5A 8ECH
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN, PNP
- Current-Collector(Ic)(Max): 5A
- Voltage-CollectorEmitterBreakdown(Max): 100V, 50V
- VceSaturation(Max)@IbIc: 120mV @ 125mA, 2.5A
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 200 @ 500mA, 2V
- Power-Max: 1.6W
- Frequency-Transition: 290MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-SMD, Flat Lead
- ECH8502-TL-H onsemi (ON), TRANS NPN/PNP 100V/50V 5A 8ECH, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
ECH8502-TL-H, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
