ECH8304-TL-E Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-ECH
- Description: MOSFET P-CH 12V 9.5A 8ECH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ECH8304-TL-E Specifications:
- MfrPart.: ECH8304-TL-E
- Mfr: Sanyo (Now Part of ONsemi)
- Description: MOSFET P-CH 12V 9.5A 8ECH
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 12 V
- Current-ContinuousDrain(Id)@25°C: 9.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): -
- RdsOn(Max)@IdVgs: 16mOhm @ 4.5A, 4.5V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 33 nC @ 4.5 V
- Vgs(Max): -
- InputCapacitance(Ciss)(Max)@Vds: 3.18 pF @ 6 V
- FETFeature: -
- PowerDissipation(Max): 1.6W (Ta)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-ECH
- ECH8304-TL-E onsemi (ON), MOSFET P-CH 12V 9.5A 8ECH, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
