CS8156YTHA5 Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: TO-220-5 Formed Leads
- Description: IC REG LIN 12V/5V TO220-5
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CS8156YTHA5 Specifications:
- MfrPart.: CS8156YTHA5
- Mfr: onsemi
- Description: IC REG LIN 12V/5V TO220-5
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tube
- Series: -
- PartStatus: Obsolete
- OutputConfiguration: Positive
- OutputType: Fixed
- NumberofRegulators: 2
- Voltage-Input(Max): 26V
- Voltage-Output(Min/Fixed): 12V, 5V
- Voltage-Output(Max): -
- VoltageDropout(Max): 1V @ 750mA, 0.6V @ 100mA
- Current-Output: 750mA, 100mA
- Current-Quiescent(Iq): 125 mA
- Current-Supply(Max): 250 mA
- PSRR: 70dB (120Hz)
- ControlFeatures: Enable
- ProtectionFeatures: Over Temperature, Over Voltage, Short Circuit
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Through Hole
- Package/Case: TO-220-5 Formed Leads
- CS8156YTHA5 onsemi (ON), IC REG LIN 12V/5V TO220-5, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
CS8156YTHA5, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
