CS8120YDR14 Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: 14-SOIC (0.154, 3.90mm Width)
- Description: IC REG LINEAR 5V 300MA 14SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CS8120YDR14 Specifications:
- MfrPart.: CS8120YDR14
- Mfr: onsemi
- Description: IC REG LINEAR 5V 300MA 14SOIC
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- OutputConfiguration: Positive
- OutputType: Fixed
- NumberofRegulators: 1
- Voltage-Input(Max): 26V
- Voltage-Output(Min/Fixed): 5V
- Voltage-Output(Max): -
- VoltageDropout(Max): 1.5V @ 200mA
- Current-Output: 300mA
- Current-Quiescent(Iq): 650 µA
- Current-Supply(Max): 15 mA
- PSRR: 70dB (120Hz)
- ControlFeatures: Enable, Reset
- ProtectionFeatures: Over Temperature, Over Voltage, Short Circuit
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 14-SOIC (0.154, 3.90mm Width)
- CS8120YDR14 onsemi (ON), IC REG LINEAR 5V 300MA 14SOIC, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
CS8120YDR14, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
