CPH6538-TL-H Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays Package/Case: SOT-23-6 Thin, TSOT-23-6
- Description: TRANS 2NPN 30V 0.7A 6CPH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CPH6538-TL-H Specifications:
- MfrPart.: CPH6538-TL-H
- Mfr: onsemi
- Description: TRANS 2NPN 30V 0.7A 6CPH
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- TransistorType: 2 NPN (Dual)
- Current-Collector(Ic)(Max): 700mA
- Voltage-CollectorEmitterBreakdown(Max): 30V
- VceSaturation(Max)@IbIc: 190mV @ 10mA, 200mA
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 300 @ 50mA, 2V
- Power-Max: 600mW
- Frequency-Transition: 540MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: SOT-23-6 Thin, TSOT-23-6
- CPH6538-TL-H onsemi (ON), TRANS 2NPN 30V 0.7A 6CPH, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
