CPH5524-TL-E Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays Package/Case: SOT-23-5 Thin, TSOT-23-5
- Description: TRANS NPN/PNP 50V 3A 5CPH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CPH5524-TL-E Specifications:
- MfrPart.: CPH5524-TL-E
- Mfr: onsemi
- Description: TRANS NPN/PNP 50V 3A 5CPH
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- TransistorType: NPN, PNP (Emitter Coupled)
- Current-Collector(Ic)(Max): 3A
- Voltage-CollectorEmitterBreakdown(Max): 50V
- VceSaturation(Max)@IbIc: 240mV @ 100mA, 2A
- Current-CollectorCutoff(Max): 1µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 200 @ 100mA, 2V
- Power-Max: 1.2W
- Frequency-Transition: 380MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: SOT-23-5 Thin, TSOT-23-5
- CPH5524-TL-E onsemi (ON), TRANS NPN/PNP 50V 3A 5CPH, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
CPH5524-TL-E, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
