CPH5505-TL-E Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays Package/Case: 5-TSSOP, SC-70-5, SOT-353
- Description: SMALL SIGNAL BIPOLAR TRANSISTOR
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CPH5505-TL-E Specifications:
- MfrPart.: CPH5505-TL-E
- Mfr: onsemi
- Description: SMALL SIGNAL BIPOLAR TRANSISTOR
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
- Package: Bulk
- Series: -
- PartStatus: Active
- TransistorType: 2 PNP (Dual)
- Current-Collector(Ic)(Max): 3A
- Voltage-CollectorEmitterBreakdown(Max): 30V
- VceSaturation(Max)@IbIc: 230mV @ 30mA, 1.5A
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 200 @ 500mA, 2V
- Power-Max: 1.2W
- Frequency-Transition: 380MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 5-TSSOP, SC-70-5, SOT-353
- CPH5505-TL-E onsemi (ON), SMALL SIGNAL BIPOLAR TRANSISTOR, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
