CPH3356-TL-H Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 3-CPH
- Description: MOSFET P-CH 20V 2.5A 3CPH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CPH3356-TL-H Specifications:
- MfrPart.: CPH3356-TL-H
- Mfr: onsemi
- Description: MOSFET P-CH 20V 2.5A 3CPH
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 2.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.8V, 4.5V
- RdsOn(Max)@IdVgs: 137mOhm @ 1A, 4.5V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 3.3 nC @ 4.5 V
- Vgs(Max): ±10V
- InputCapacitance(Ciss)(Max)@Vds: 250 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 1W (Ta)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 3-CPH
- CPH3356-TL-H onsemi (ON), MOSFET P-CH 20V 2.5A 3CPH, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
CPH3356-TL-H, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
