CPH3101-TL-E onsemi SMALL SIGNAL BIPOLAR TRANSISTOR
CPH3101-TL-E Images
CPH3101-TL-E Images
CPH3101-TL-E
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: 3-SMD, Gull Wing
  • Description: SMALL SIGNAL BIPOLAR TRANSISTOR
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
CPH3101-TL-E Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
CPH3101-TL-E Specifications:
  • MfrPart.: CPH3101-TL-E
  • Mfr: onsemi
  • Description: SMALL SIGNAL BIPOLAR TRANSISTOR
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Bulk
  • Series: -
  • PartStatus: Active
  • TransistorType: PNP
  • Current-Collector(Ic)(Max): 2 A
  • Voltage-CollectorEmitterBreakdown(Max): 30 V
  • VceSaturation(Max)@IbIc: 600mV @ 75mA, 1.5A
  • Current-CollectorCutoff(Max): 100nA (ICBO)
  • DCCurrentGain(hFE)(Min)@IcVce: 200 @ 100mA, 2V
  • Power-Max: 900 mW
  • Frequency-Transition: 150MHz
  • OperatingTemperature: 150°C (TJ)
  • MountingType: Surface Mount
  • Package/Case: 3-SMD, Gull Wing
  • CPH3101-TL-E onsemi (ON), SMALL SIGNAL BIPOLAR TRANSISTOR, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
