CM1426-06CP onsemi DATA LINE FILTER, 6 FUNCTION(S)
CM1426-06CP Images
CM1426-06CP Images
  • Manufacturer: onsemi (ON)
  • Category: Filters~EMI-RFI Filters (LC, RC Networks) Package/Case: 15-WFBGA, WLCSP
  • Description: DATA LINE FILTER, 6 FUNCTION(S)
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
CM1426-06CP Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
CM1426-06CP Specifications:
  • MfrPart.: CM1426-06CP
  • Mfr: onsemi
  • Description: DATA LINE FILTER, 6 FUNCTION(S)
  • Product Category: Filters~EMI-RFI Filters (LC, RC Networks)
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • Type: Low Pass
  • FilterOrder: 2nd
  • Technology: RC (Pi)
  • NumberofChannels: 6
  • Center/CutoffFrequency: 230MHz (Cutoff)
  • AttenuationValue: 20dB @ 1GHz
  • Resistance-Channel(Ohms): 100
  • Current: -
  • Values: R = 100Ohms, C = 8.5pF
  • ESDProtection: Yes
  • OperatingTemperature: -40°C ~ 85°C
  • Applications: Data Lines for Mobile Devices
  • Voltage-Rated: -
  • MountingType: Surface Mount
  • Package/Case: 15-WFBGA, WLCSP
  • Size/Dimension: 0.117 L x 0.052 W (2.96mm x 1.33mm)
  • CM1426-06CP onsemi (ON), DATA LINE FILTER, 6 FUNCTION(S), Filters~EMI-RFI Filters (LC, RC Networks)
