CM1420-03CP Images
- Manufacturer: onsemi (ON)
- Category: Filters~EMI-RFI Filters (LC, RC Networks) Package/Case: 15-WFBGA, WLCSP
- Description: DATA LINE FILTER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CM1420-03CP Specifications:
- MfrPart.: CM1420-03CP
- Mfr: onsemi
- Description: DATA LINE FILTER
- Product Category: Filters~EMI-RFI Filters (LC, RC Networks)
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- Type: Low Pass
- FilterOrder: 2nd
- Technology: RC (Pi)
- NumberofChannels: 6
- Center/CutoffFrequency: 120MHz (Cutoff)
- AttenuationValue: 30dB @ 1GHz ~ 3GHz
- Resistance-Channel(Ohms): 100
- Current: -
- Values: R = 100Ohms, C = 15pF
- ESDProtection: Yes
- OperatingTemperature: -40°C ~ 85°C
- Applications: Data Lines for Mobile Devices
- Voltage-Rated: -
- MountingType: Surface Mount
- Package/Case: 15-WFBGA, WLCSP
- Size/Dimension: 0.117 L x 0.052 W (2.96mm x 1.33mm)
- CM1420-03CP onsemi (ON), DATA LINE FILTER, Filters~EMI-RFI Filters (LC, RC Networks)
CM1420-03CP, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
