CD4053BCN Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: IC MUX/DEMUX TRIPLE 2X1 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CD4053BCN Specifications:
- MfrPart.: CD4053BCN
- Mfr: onsemi
- Description: IC MUX/DEMUX TRIPLE 2X1 16DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 3
- On-StateResistance(Max): 240Ohm
- Channel-to-ChannelMatching(ΔRon): 5Ohm
- Voltage-SupplySingle(V+): 5V ~ 15V
- Voltage-SupplyDual(V±): ±2.5V ~ 7.5V
- SwitchTime(TonToff)(Max): 320ns, 150ns
- -3dbBandwidth: 40MHz
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): -
- Current-Leakage(IS(off))(Max): 50nA
- Crosstalk: -40dB @ 3MHz
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- CD4053BCN onsemi (ON), IC MUX/DEMUX TRIPLE 2X1 16DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
CD4053BCN, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
