BS170RLRAG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-92 (TO-226)
- Description: MOSFET N-CH 60V 500MA TO92-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BS170RLRAG Specifications:
- MfrPart.: BS170RLRAG
- Mfr: onsemi
- Description: MOSFET N-CH 60V 500MA TO92-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 500mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 5Ohm @ 200mA, 10V
- Vgs(th)(Max)@Id: 3V @ 1mA
- GateCharge(Qg)(Max)@Vgs: -
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 60 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 350mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-92 (TO-226)
- BS170RLRAG onsemi (ON), MOSFET N-CH 60V 500MA TO92-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
BS170RLRAG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
