BDW47 onsemi TRANS PNP DARL 100V 15A TO220AB
BDW47 Images
BDW47 Images
BDW47
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-220-3
  • Description: TRANS PNP DARL 100V 15A TO220AB
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
BDW47 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
BDW47 Specifications:
  • MfrPart.: BDW47
  • Mfr: onsemi
  • Description: TRANS PNP DARL 100V 15A TO220AB
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • TransistorType: PNP - Darlington
  • Current-Collector(Ic)(Max): 15 A
  • Voltage-CollectorEmitterBreakdown(Max): 100 V
  • VceSaturation(Max)@IbIc: 3V @ 50mA, 10A
  • Current-CollectorCutoff(Max): 2mA
  • DCCurrentGain(hFE)(Min)@IcVce: 1000 @ 5A, 4V
  • Power-Max: 85 W
  • Frequency-Transition: 4MHz
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-220-3
  • BDW47 onsemi (ON), TRANS PNP DARL 100V 15A TO220AB, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
