BD1766STU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-225AA, TO-126-3
- Description: TRANS PNP 45V 3A TO-126
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BD1766STU Specifications:
- MfrPart.: BD1766STU
- Mfr: onsemi
- Description: TRANS PNP 45V 3A TO-126
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- TransistorType: PNP
- Current-Collector(Ic)(Max): 3 A
- Voltage-CollectorEmitterBreakdown(Max): 45 V
- VceSaturation(Max)@IbIc: 800mV @ 100mA, 1A
- Current-CollectorCutoff(Max): 100µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 40 @ 150mA, 2V
- Power-Max: 30 W
- Frequency-Transition: 3MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-225AA, TO-126-3
- BD1766STU onsemi (ON), TRANS PNP 45V 3A TO-126, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
BD1766STU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
onsemi (ON) Authorized Distributor | NHE is dedicated to providing first-quality, genuine onsemi components.
