BD1396STU onsemi TRANS NPN 80V 1.5A TO-126
BD1396STU Images
BD1396STU Images
BD1396STU
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-225AA, TO-126-3
  • Description: TRANS NPN 80V 1.5A TO-126
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
BD1396STU Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
BD1396STU Specifications:
  • MfrPart.: BD1396STU
  • Mfr: onsemi
  • Description: TRANS NPN 80V 1.5A TO-126
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • TransistorType: NPN
  • Current-Collector(Ic)(Max): 1.5 A
  • Voltage-CollectorEmitterBreakdown(Max): 80 V
  • VceSaturation(Max)@IbIc: 500mV @ 50mA, 500mA
  • Current-CollectorCutoff(Max): 100nA (ICBO)
  • DCCurrentGain(hFE)(Min)@IcVce: 40 @ 150mA, 2V
  • Power-Max: 1.25 W
  • Frequency-Transition: -
  • OperatingTemperature: 150°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-225AA, TO-126-3
  • BD1396STU onsemi (ON), TRANS NPN 80V 1.5A TO-126, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
