BD138 onsemi GENERAL PURPOSE PNP TRANSISTOR
BD138 Images
BD138 Images
BD138
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-225AA, TO-126-3
  • Description: GENERAL PURPOSE PNP TRANSISTOR
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
BD138 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
BD138 Specifications:
  • MfrPart.: BD138
  • Mfr: onsemi
  • Description: GENERAL PURPOSE PNP TRANSISTOR
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • TransistorType: PNP
  • Current-Collector(Ic)(Max): 1.5 A
  • Voltage-CollectorEmitterBreakdown(Max): 60 V
  • VceSaturation(Max)@IbIc: 500mV @ 50mA, 500mA
  • Current-CollectorCutoff(Max): 100nA (ICBO)
  • DCCurrentGain(hFE)(Min)@IcVce: 40 @ 150mA, 2V
  • Power-Max: 1.25 W
  • Frequency-Transition: -
  • OperatingTemperature: 150°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-225AA, TO-126-3
  • BD138 onsemi (ON), GENERAL PURPOSE PNP TRANSISTOR, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
