BCX56-10R1 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-243AA
- Description: TRANS NPN 80V 1A SOT89
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BCX56-10R1 Specifications:
- MfrPart.: BCX56-10R1
- Mfr: onsemi
- Description: TRANS NPN 80V 1A SOT89
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 1 A
- Voltage-CollectorEmitterBreakdown(Max): 80 V
- VceSaturation(Max)@IbIc: 500mV @ 50mA, 500mA
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 63 @ 150mA, 2V
- Power-Max: 1.56 W
- Frequency-Transition: 130MHz
- OperatingTemperature: -65°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-243AA
- BCX56-10R1 onsemi (ON), TRANS NPN 80V 1A SOT89, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
