BCP56T1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-261-4, TO-261AA
- Description: TRANS NPN 80V 1A SOT223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BCP56T1G Specifications:
- MfrPart.: BCP56T1G
- Mfr: onsemi
- Description: TRANS NPN 80V 1A SOT223
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 1 A
- Voltage-CollectorEmitterBreakdown(Max): 80 V
- VceSaturation(Max)@IbIc: 500mV @ 50mA, 500mA
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 40 @ 150mA, 2V
- Power-Max: 1.5 W
- Frequency-Transition: 130MHz
- OperatingTemperature: -65°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-261-4, TO-261AA
- BCP56T1G onsemi (ON), TRANS NPN 80V 1A SOT223, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
BCP56T1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
