BC560ATA Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- Description: TRANS PNP 45V 0.1A TO-92
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BC560ATA Specifications:
- MfrPart.: BC560ATA
- Mfr: onsemi
- Description: TRANS PNP 45V 0.1A TO-92
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Box (TB)
- Series: -
- PartStatus: Obsolete
- TransistorType: PNP
- Current-Collector(Ic)(Max): 100 mA
- Voltage-CollectorEmitterBreakdown(Max): 45 V
- VceSaturation(Max)@IbIc: 650mV @ 5mA, 100mA
- Current-CollectorCutoff(Max): 15nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 110 @ 2mA, 5V
- Power-Max: 500 mW
- Frequency-Transition: 150MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- BC560ATA onsemi (ON), TRANS PNP 45V 0.1A TO-92, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
BC560ATA, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
