BAWH56WT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: SC-70, SOT-323
- Description: 70V ANODE DIODE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BAWH56WT1G Specifications:
- Manufacturer Product Number: BAWH56WT1G
- Mfr: onsemi
- Detailed Description: 70V ANODE DIODE
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tape & Reel (TR)
- Series: -
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 70 V
- Current - Average Rectified (Io): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 6 ns
- Current - Reverse Leakage @ Vr: 2.5 µA @ 70 V
- Capacitance @ Vr, F: 2pF @ 0V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: SC-70, SOT-323
- Operating Temperature - Junction: -55°C ~ 175°C
- BAWH56WT1G onsemi (ON), 70V ANODE DIODE, Discrete Semiconductor Products~Diodes - Rectifiers - Single
BAWH56WT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
