BAW56TT1 onsemi DIODE ARRAY GP 70V 200MA SC75
BAW56TT1 Images
BAW56TT1 Images
BAW56TT1
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: SC-75, SOT-416
  • Description: DIODE ARRAY GP 70V 200MA SC75
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
BAW56TT1 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
BAW56TT1 Specifications:
  • Mfr Part: BAW56TT1
  • Mfr: onsemi
  • Description: DIODE ARRAY GP 70V 200MA SC75
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
  • Item12: Tape & Reel (TR)
  • Series: -
  • Part Status: Obsolete
  • Diode Configuration: 1 Pair Common Anode
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 70 V
  • Current - Average Rectified (Io) (per Diode): 200mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Current - Reverse Leakage @ Vr: 2.5 µA @ 70 V
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Mounting Type: Surface Mount
  • Package / Case: SC-75, SOT-416
  • BAW56TT1 onsemi (ON), DIODE ARRAY GP 70V 200MA SC75, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
