BAW56 onsemi DIODE ARRAY GP 85V 200MA SOT23-3
BAW56 Images
BAW56 Images
BAW56
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: TO-236-3, SC-59, SOT-23-3
  • Description: DIODE ARRAY GP 85V 200MA SOT23-3
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
BAW56 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
BAW56 Specifications:
  • Mfr Part: BAW56
  • Mfr: onsemi
  • Description: DIODE ARRAY GP 85V 200MA SOT23-3
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
  • Item12: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • Part Status: Obsolete
  • Diode Configuration: 1 Pair Common Anode
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 85 V
  • Current - Average Rectified (Io) (per Diode): 200mA
  • Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Current - Reverse Leakage @ Vr: 2.5 µA @ 70 V
  • Operating Temperature - Junction: 150°C (Max)
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • BAW56 onsemi (ON), DIODE ARRAY GP 85V 200MA SOT23-3, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
