BAT54T1 onsemi RECTIFIER DIODE
BAT54T1 Images
BAT54T1 Images
BAT54T1
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: SOD-123
  • Description: RECTIFIER DIODE
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
BAT54T1 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
BAT54T1 Specifications:
  • Manufacturer Product Number: BAT54T1
  • Mfr: onsemi
  • Detailed Description: RECTIFIER DIODE
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
  • Package: Bulk
  • Series: -
  • Part Status: Obsolete
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 30 V
  • Current - Average Rectified (Io): 200mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 800 mV @ 100 mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Reverse Recovery Time (trr): 5 ns
  • Current - Reverse Leakage @ Vr: 2 µA @ 25 V
  • Capacitance @ Vr, F: 10pF @ 1V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: SOD-123
  • Operating Temperature - Junction: -
  • BAT54T1 onsemi (ON), RECTIFIER DIODE, Discrete Semiconductor Products~Diodes - Rectifiers - Single
