BAT54T Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: TO-236-3, SC-59, SOT-23-3
- Description: DIODE SCHOTTKY 30V 200MA SOT523
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BAT54T Specifications:
- Manufacturer Product Number: BAT54T
- Mfr: onsemi
- Detailed Description: DIODE SCHOTTKY 30V 200MA SOT523
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- Part Status: Obsolete
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io): 200mA
- Voltage - Forward (Vf) (Max) @ If: 1 V @ 100 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 5 ns
- Current - Reverse Leakage @ Vr: 2 µA @ 25 V
- Capacitance @ Vr, F: 10pF @ 1V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Operating Temperature - Junction: 125°C (Max)
- BAT54T onsemi (ON), DIODE SCHOTTKY 30V 200MA SOT523, Discrete Semiconductor Products~Diodes - Rectifiers - Single
