ATP204-TL-H Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: ATPAK
- Description: MOSFET N-CH 30V 100A ATPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ATP204-TL-H Specifications:
- MfrPart.: ATP204-TL-H
- Mfr: onsemi
- Description: MOSFET N-CH 30V 100A ATPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 100A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 5.6mOhm @ 50A, 10V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 70 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 4600 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 60W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: ATPAK
- ATP204-TL-H onsemi (ON), MOSFET N-CH 30V 100A ATPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
