AFGY160T65SPD-B4 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT - 650V, 160A FIELD STOP TRE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AFGY160T65SPD-B4 Specifications:
- MfrPart.: AFGY160T65SPD-B4
- Mfr: onsemi
- Description: IGBT - 650V, 160A FIELD STOP TRE
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Automotive, AEC-Q100
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 240 A
- Current-CollectorPulsed(Icm): 480 A
- Vce(on)(Max)@VgeIc: 2.05V @ 15V, 160A
- Power-Max: 882 W
- SwitchingEnergy: 12.4mJ (on), 5.7mJ (off)
- InputType: Standard
- GateCharge: 245 nC
- Td(on/off)@25°C: 53ns/98ns
- TestCondition: 400V, 160A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 132 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- AFGY160T65SPD-B4 onsemi (ON), IGBT - 650V, 160A FIELD STOP TRE, Discrete Semiconductor Products~Transistors - IGBTs - Single
