AFGY120T65SPD Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT - 650 V 120 A FS3 FOR EV TR
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AFGY120T65SPD Specifications:
- MfrPart.: AFGY120T65SPD
- Mfr: onsemi
- Description: IGBT - 650 V 120 A FS3 FOR EV TR
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: -
- Series: Automotive, AEC-Q101
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 160 A
- Current-CollectorPulsed(Icm): 360 A
- Vce(on)(Max)@VgeIc: 2.05V @ 15V, 120A
- Power-Max: 714 W
- SwitchingEnergy: 6.6mJ (on), 3.8mJ (off)
- InputType: Standard
- GateCharge: 125 nC
- Td(on/off)@25°C: 40ns/80ns
- TestCondition: 400V, 120A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 107 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- AFGY120T65SPD onsemi (ON), IGBT - 650 V 120 A FS3 FOR EV TR, Discrete Semiconductor Products~Transistors - IGBTs - Single
AFGY120T65SPD, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
