AFGY100T65SPD Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT - 650 V 100 A FS3 FOR EV TR
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AFGY100T65SPD Specifications:
- MfrPart.: AFGY100T65SPD
- Mfr: onsemi
- Description: IGBT - 650 V 100 A FS3 FOR EV TR
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Automotive, AEC-Q101
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 120 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 2.05V @ 15V, 100A
- Power-Max: 660 W
- SwitchingEnergy: 5.1mJ (on), 2.7mJ (off)
- InputType: Standard
- GateCharge: 109 nC
- Td(on/off)@25°C: 36ns/78ns
- TestCondition: 400V, 100A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 105 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- AFGY100T65SPD onsemi (ON), IGBT - 650 V 100 A FS3 FOR EV TR, Discrete Semiconductor Products~Transistors - IGBTs - Single
