AFGHL75T65SQDT Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: 650V/75A FS4 IGBT TO247 L
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AFGHL75T65SQDT Specifications:
- MfrPart.: AFGHL75T65SQDT
- Mfr: onsemi
- Description: 650V/75A FS4 IGBT TO247 L
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Automotive, AEC-Q101
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 75A
- Power-Max: 375 W
- SwitchingEnergy: 2.12mJ (on), 1.14mJ (off)
- InputType: Standard
- GateCharge: 136 nC
- Td(on/off)@25°C: 24ns/106ns
- TestCondition: 400V, 75A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): 75 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- AFGHL75T65SQDT onsemi (ON), 650V/75A FS4 IGBT TO247 L, Discrete Semiconductor Products~Transistors - IGBTs - Single
