AFGHL75T65SQ Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT WITH SIC COPACK DIODE IGBT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AFGHL75T65SQ Specifications:
- MfrPart.: AFGHL75T65SQ
- Mfr: onsemi
- Description: IGBT WITH SIC COPACK DIODE IGBT
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Automotive, AEC-Q101
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 75A
- Power-Max: 375 W
- SwitchingEnergy: 1.86mJ (on), 1.13mJ (off)
- InputType: Standard
- GateCharge: 139 nC
- Td(on/off)@25°C: 25ns/106ns
- TestCondition: 400V, 75A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- AFGHL75T65SQ onsemi (ON), IGBT WITH SIC COPACK DIODE IGBT, Discrete Semiconductor Products~Transistors - IGBTs - Single
AFGHL75T65SQ, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
