AFGHL50T65SQDC Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 650V A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AFGHL50T65SQDC Specifications:
- MfrPart.: AFGHL50T65SQDC
- Mfr: onsemi
- Description: IGBT 650V A
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Automotive, AEC-Q101
- PartStatus: Active
- IGBTType: Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 100 A
- Current-CollectorPulsed(Icm): 200 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 50A
- Power-Max: 238 W
- SwitchingEnergy: 131µJ (on), 96µJ (off)
- InputType: Standard
- GateCharge: 94 nC
- Td(on/off)@25°C: 17.6ns/94.4ns
- TestCondition: 400V, 12.5A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- AFGHL50T65SQDC onsemi (ON), IGBT 650V A, Discrete Semiconductor Products~Transistors - IGBTs - Single
