AFGHL40T65SQD Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: AEC 101 QUALIFIED, 650V, 40A FIE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AFGHL40T65SQD Specifications:
- MfrPart.: AFGHL40T65SQD
- Mfr: onsemi
- Description: AEC 101 QUALIFIED, 650V, 40A FIE
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Automotive, AEC-Q101
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 40A
- Power-Max: 238 W
- SwitchingEnergy: 250µJ (on), 90µJ (off)
- InputType: Standard
- GateCharge: 68 nC
- Td(on/off)@25°C: 15ns/70ns
- TestCondition: 400V, 20A, 6Ohm, 15V
- ReverseRecoveryTime(trr): 28 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- AFGHL40T65SQD onsemi (ON), AEC 101 QUALIFIED, 650V, 40A FIE, Discrete Semiconductor Products~Transistors - IGBTs - Single
