74VCX38BQX Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-DQFN (3x2.5)
- Description: IC GATE NAND OD 4CH 2-INP 14DQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
74VCX38BQX Specifications:
- MfrPart.: 74VCX38BQX
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: IC GATE NAND OD 4CH 2-INP 14DQFN
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Bulk
- Series: 74VCX
- PartStatus: Obsolete
- LogicType: NAND Gate
- NumberofCircuits: 4
- NumberofInputs: 2
- Features: Open Drain
- Voltage-Supply: 1.2V ~ 3.6V
- Current-Quiescent(Max): 20 µA
- Current-OutputHighLow: -, 24mA
- LogicLevel-Low: 0.7V ~ 0.8V
- LogicLevel-High: 1.6V ~ 2V
- MaxPropagationDelay@VMaxCL: 2.8ns @ 3.3V, 30pF
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- SupplierDevicePackage: 14-DQFN (3x2.5)
- 74VCX38BQX onsemi (ON), IC GATE NAND OD 4CH 2-INP 14DQFN, Integrated Circuits (ICs)~Logic - Gates and Inverters
74VCX38BQX, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
