74LCX38MX onsemi IC GATE NAND OD 4CH 2-INP 14SOIC
74LCX38MX Images
74LCX38MX Images
74LCX38MX
  • Manufacturer: onsemi (ON)
  • Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-SOIC
  • Description: IC GATE NAND OD 4CH 2-INP 14SOIC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
74LCX38MX Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
74LCX38MX Specifications:
  • MfrPart.: 74LCX38MX
  • Mfr: onsemi
  • Description: IC GATE NAND OD 4CH 2-INP 14SOIC
  • Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: 74LCX
  • PartStatus: Active
  • LogicType: NAND Gate
  • NumberofCircuits: 4
  • NumberofInputs: 2
  • Features: Open Drain
  • Voltage-Supply: 2V ~ 3.6V
  • Current-Quiescent(Max): 10 µA
  • Current-OutputHighLow: -, 24mA
  • LogicLevel-Low: 0.7V ~ 0.8V
  • LogicLevel-High: 1.7V ~ 2V
  • MaxPropagationDelay@VMaxCL: 5ns @ 3.3V, 50pF
  • OperatingTemperature: -40°C ~ 85°C
  • MountingType: Surface Mount
  • SupplierDevicePackage: 14-SOIC
  • 74LCX38MX onsemi (ON), IC GATE NAND OD 4CH 2-INP 14SOIC, Integrated Circuits (ICs)~Logic - Gates and Inverters
