74F109SJX onsemi IC FF JK TYPE DUAL 1BIT 16SOP
74F109SJX Images
74F109SJX Images
74F109SJX
  • Manufacturer: onsemi (ON)
  • Category: Integrated Circuits (ICs)~Logic - Flip Flops SupplierDevicePackage: 16-SOP
  • Description: IC FF JK TYPE DUAL 1BIT 16SOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
74F109SJX Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
74F109SJX Specifications:
  • MfrPart.: 74F109SJX
  • Mfr: onsemi
  • Description: IC FF JK TYPE DUAL 1BIT 16SOP
  • Product Category: Integrated Circuits (ICs)~Logic - Flip Flops
  • Package: Tape & Reel (TR)
  • Series: 74F
  • PartStatus: Obsolete
  • Function: Set(Preset) and Reset
  • Type: JK Type
  • OutputType: Complimentary
  • NumberofElements: 2
  • NumberofBitsperElement: 1
  • ClockFrequency: 125 MHz
  • MaxPropagationDelay@VMaxCL: 8ns @ 5V, 50pF
  • TriggerType: Positive Edge
  • Current-OutputHighLow: 1mA, 20mA
  • Voltage-Supply: 4.5V ~ 5.5V
  • Current-Quiescent(Iq): 17 mA
  • InputCapacitance: -
  • OperatingTemperature: 0°C ~ 70°C (TA)
  • MountingType: Surface Mount
  • SupplierDevicePackage: 16-SOP
  • 74F109SJX onsemi (ON), IC FF JK TYPE DUAL 1BIT 16SOP, Integrated Circuits (ICs)~Logic - Flip Flops
