74AC109SCX Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~Logic - Flip Flops SupplierDevicePackage: 16-SOIC
- Description: IC FF JK TYPE DUAL 1BIT 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
74AC109SCX Specifications:
- MfrPart.: 74AC109SCX
- Mfr: onsemi
- Description: IC FF JK TYPE DUAL 1BIT 16SOIC
- Product Category: Integrated Circuits (ICs)~Logic - Flip Flops
- Package: Tape & Reel (TR)
- Series: 74AC
- PartStatus: Obsolete
- Function: Set(Preset) and Reset
- Type: JK Type
- OutputType: Complimentary
- NumberofElements: 2
- NumberofBitsperElement: 1
- ClockFrequency: 175 MHz
- MaxPropagationDelay@VMaxCL: 10ns @ 5V, 50pF
- TriggerType: Positive Edge
- Current-OutputHighLow: 24mA, 24mA
- Voltage-Supply: 2V ~ 6V
- Current-Quiescent(Iq): 2 µA
- InputCapacitance: 4.5 pF
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- SupplierDevicePackage: 16-SOIC
- 74AC109SCX onsemi (ON), IC FF JK TYPE DUAL 1BIT 16SOIC, Integrated Circuits (ICs)~Logic - Flip Flops
