6N137 onsemi OPTOISO 2.5KV 1CH OPEN COLL 8DIP
6N137 Images
6N137 Images
6N137
  • Manufacturer: onsemi (ON)
  • Category: Isolators~Optoisolators - Logic Output Package/Case: 8-DIP (0.300, 7.62mm)
  • Description: OPTOISO 2.5KV 1CH OPEN COLL 8DIP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
6N137 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
6N137 Specifications:
  • MfrPart.: 6N137
  • Mfr: onsemi
  • Description: OPTOISO 2.5KV 1CH OPEN COLL 8DIP
  • Product Category: Isolators~Optoisolators - Logic Output
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • NumberofChannels: 1
  • Inputs-Side1/Side2: 1/0
  • Voltage-Isolation: 2500Vrms
  • CommonModeTransientImmunity(Min): 10kV/µs (Typ)
  • InputType: DC
  • OutputType: Open Collector
  • Current-Output/Channel: 50 mA
  • DataRate: 10Mbps
  • PropagationDelaytpLH/tpHL(Max): 75ns, 75ns
  • Rise/FallTime(Typ): 50ns, 12ns
  • Voltage-Forward(Vf)(Typ): 1.4V
  • Current-DCForward(If)(Max): 50mA
  • Voltage-Supply: 4.5V ~ 5.5V
  • OperatingTemperature: -40°C ~ 85°C
  • MountingType: Through Hole
  • Package/Case: 8-DIP (0.300, 7.62mm)
  • 6N137 onsemi (ON), OPTOISO 2.5KV 1CH OPEN COLL 8DIP, Isolators~Optoisolators - Logic Output
