4N30M Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 6-DIP (0.400, 10.16mm)
- Description: GENERAL PURPOSE PHOTODARLINGTON
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
4N30M Specifications:
- MfrPart.: 4N30M
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: GENERAL PURPOSE PHOTODARLINGTON
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Bulk
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CurrentTransferRatio(Min): 100% @ 10mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 5µs, 40µs (Max)
- Rise/FallTime(Typ): -
- InputType: DC
- OutputType: Darlington with Base
- Voltage-Output(Max): 55V
- Current-Output/Channel: -
- Voltage-Forward(Vf)(Typ): 1.2V
- Current-DCForward(If)(Max): 60 mA
- VceSaturation(Max): 1V
- OperatingTemperature: -55°C ~ 100°C
- MountingType: Through Hole
- Package/Case: 6-DIP (0.400, 10.16mm)
- 4N30M onsemi (ON), GENERAL PURPOSE PHOTODARLINGTON, Isolators~Optoisolators - Transistor, Photovoltaic Output
4N30M, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
