4N29TVM Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 6-DIP (0.400, 10.16mm)
- Description: OPTOISO 4.17KV TRANS W/BASE 6DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
4N29TVM Specifications:
- MfrPart.: 4N29TVM
- Mfr: onsemi
- Description: OPTOISO 4.17KV TRANS W/BASE 6DIP
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Obsolete
- NumberofChannels: 1
- Voltage-Isolation: 4170Vrms
- CurrentTransferRatio(Min): 100% @ 10mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 5µs, 40µs (Max)
- Rise/FallTime(Typ): -
- InputType: DC
- OutputType: Darlington with Base
- Voltage-Output(Max): 30V
- Current-Output/Channel: 150mA
- Voltage-Forward(Vf)(Typ): 1.2V
- Current-DCForward(If)(Max): 80 mA
- VceSaturation(Max): 1V
- OperatingTemperature: -40°C ~ 100°C
- MountingType: Through Hole
- Package/Case: 6-DIP (0.400, 10.16mm)
- 4N29TVM onsemi (ON), OPTOISO 4.17KV TRANS W/BASE 6DIP, Isolators~Optoisolators - Transistor, Photovoltaic Output
4N29TVM, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
